Very few if any Z77 motherboards will have slots for 8 RAM sticks, 4x8GB is maximum. So 4x4GB or 2x8GB are your options. Low profile RAMs dont have stupid decoration heatsinks that are 100% unnecessary. In some cases those tall heatsinks get in the way of CPU coolers which is why those are bad purchase. Details about ASRock Z77 Extreme4. Motherboard LGA775/1150/1151/1155 DDR3 Memory PCI-E X16. Z77 Extreme4 Motherboard, Working, 4X DDR3 Slots, LGA1155 CPU Socket. So I'm planning on getting the ASRock Z77 Extreme4. My questions are: 1. This is pretty self-explanatory but I still want confirmation. This means it can ONLY fit 4 RAMs that are 240 pin? Do I have to fill all 4 slots or is it not necessary? It says Maximum Memory Supported: 32GB. So this means the maximum amount of RAM it can support is 32gb. Would it harm the. Z77 Extreme4 motherboard pdf manual download. You can use ASRock XFast RAM to utilize the memory that Win- ® dows cannot use. DIMM slots, and supports Dual. Dual Channel Memory not working on my ASRock Z77 Extreme4 Hi all, I've been running low on RAM on my PC (build here) using Windows 7 Ultimate SP1, and I've been trying to upgrade my RAM by adding two new sticks of the same kind of RAM.

Z77 Extreme4 Ram Slots Upgrade

• - Supports 3^rd and 2^nd Generation Intel^® Core™ i7 / i5 / i3 / Xeon^® / Pentium^® / Celeron^® in LGA1155 Package
  - Digi Power Design
  - 8 + 4 Power Phase Design
  - Supports Intel^® Turbo Boost 2.0 Technology
  - Supports Intel^® K-Series unlocked CPU
  - Supports Hyper-Threading Technology
• - Intel^® Z77
  - Supports Intel^® Rapid Start Technology and Smart Connect Technology


  *Intel^® Rapid Start Technology and Smart Connect Technology are only supported under Windows^® 7 OS or later versions.
• - Dual Channel DDR3 memory technology
  - 4 x DDR3 DIMM slots
  - Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered memory
  - Max. capacity of system memory: 32GB*
  - Supports Intel^® Extreme Memory Profile (XMP) 1.3 / 1.2


  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
  **In order to maximize the system memory, please install 8GB memory module with 16 cells
• - 64Mb AMI UEFI Legal BIOS with GUI support
  - Supports 'Plug and Play'
  - ACPI 1.1 Compliance Wake Up Events
  - Supports jumperfree
  - SMBIOS 2.3.1 Support
  - CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage Multi-adjustment
• - Supports Intel^® HD Graphics Built-in Visuals : Intel^® Quick Sync Video 2.0, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® Insider™, Intel^® HD Graphics 2500/4000 with Intel^® Ivy Bridge CPU
  - Supports Intel^® HD Graphics Built-in Visuals : Intel^® Quick Sync Video, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® HD Graphics 2000/3000, Intel^® Advanced Vector Extensions (AVX) with Intel^® Sandy Bridge CPU
  - Pixel Shader 5.0, DirectX 11 with Intel^® Ivy Bridge CPU. Pixel Shader 4.1, DirectX 10.1 with Intel^® Sandy Bridge CPU
  - Max. shared memory 1760MB with Intel^® Ivy Bridge CPU. Max. shared memory 1759MB with Intel^® Sandy Bridge CPU
  - Three graphics output options: D-Sub, DVI-D and HDMI
  - Supports HDMI Technology with max. resolution up to 1920x1200 @ 60Hz
  - Supports DVI with max. resolution up to 1920x1200 @ 60Hz
  - Supports D-Sub with max. resolution up to 2048x1536 @ 75Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI (Compliant HDMI monitor is required)
  - Supports HDCP function with DVI and HDMI ports
  - Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI and HDMI ports


  *Intel^® HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
  **Due to chipset limitation, the Blu-ray playback of Intel^® HD Graphics is only supported under Windows^® Vista™ and Windows^® 7.
  ***Intel^® InTru™ 3D is only supported under Windows^® 7 and Windows^® 7 x64.
• - 7.1 CH HD Audio with Content Protection (Realtek ALC898 Audio Codec)
  - Premium Blu-ray audio support
• - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Broadcom BCM57781
  - Supports Wake-On-LAN
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• - 2 x PCI Express 3.0 x16 slots (PCIE2/PCIE3: single at x16 (PCIE2) / x8 (PCIE3) or dual at x8/x8 mode)
  - 2 x PCI Express 2.0 x1 slots
  - 2 x PCI slots
  - Supports AMD Quad CrossFireX™ and CrossFireX™
  - Supports NVIDIA^® Quad SLI™ and SLI™


  *PCIe Gen3 is supported on 3^rd Generation of Intel^® Core™ i5 and Core™ i7 CPUs.
• - 2 x SATA3 6.0 Gb/s connectors by Intel^® Z77, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug functions
  - 2 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug functions (SATA3_A1 connector is shared with eSATA3 port)
• - 2 x Rear USB 3.1 Gen1 ports by Intel^® Z77, support USB 1.0/2.0/3.0 up to 5Gb/s
  - 2 x Rear USB 3.1 Gen1 ports by ASMedia ASM1042, support USB 1.0/2.0/3.0 up to 5Gb/s
  - 1 x Front USB 3.1 Gen1 header by Intel^® Z77 (supports 2 USB 3.1 Gen1 ports), supports USB 1.0/2.0/3.0 up to 5Gb/s
• - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug functions
  - 4 x SATA3 6.0 Gb/s connectors
  - 1 x IR header
  - 1 x CIR header
  - 1 x COM port header
  - 1 x HDMI_SPDIF header
  - 1 x Power LED header
  - 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)
  - 3 x Chassis Fan connectors (1 x 4-pin, 2 x 3-pin)
  - 1 x Power Fan connector (3-pin)
  - 24 pin ATX power connector
  - 8 pin 12V power connector
  - Front panel audio connector
  - 3 x USB 2.0 headers (support 6 USB 2.0 ports)
  - 1 x USB 3.1 Gen1 header (supports 2 USB 3.1 Gen1 ports)
  - 1 x Dr. Debug with LED*
  - 1 x Power Switch with LED
  - 1 x Reset Switch with LED
  - 1 x Clear CMOS Switch with LED

• Rear Panel I/O
  I/O Panel
  - 1 x PS/2 Keyboard/Mouse Port
  - 1 x D-Sub Port
  - 1 x DVI-D Port
  - 1 x HDMI Port
  - 1 x Optical SPDIF Out Port
  - 2 x Ready-to-Use USB 2.0 Ports
  - 1 x eSATA3 Connector
  - 4 x Ready-to-Use USB 3.1 Gen1 Ports
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - 1 x Clear CMOS Switch with LED
  - HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• - ASRock Extreme Tuning Utility (AXTU)
  - ASRock Instant Boot
  - ASRock Instant Flash
  - ASRock APP Charger
  - ASRock XFast USB
  - ASRock XFast LAN
  - ASRock XFast RAM
  - ASRock Crashless BIOS
  - ASRock OMG (Online Management Guard)
  - ASRock Internet Flash
  - ASRock Dehumidifier Function
  - ASRock No-K OC Technology
  - Lucid Virtu Universal MVP
  - Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
  - Combo Cooler Option (C.C.O.)
  - Good Night LED


  *Lucid Virtu Universal MVP can be supported only with processors which are GPU integrated.
  **LucidLogix Virtu MVP only supports Windows^® 7 or Windows^® 8.
• - Drivers, Utilities, AntiVirus Software (Trial Version), CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX Multimedia Suite - Trial
• - 1 x ASRock SLI_Bridge_2S Card
  - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables
• - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU, Chassis, Power Fan Tachometer
  - CPU, Chassis Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
  - CPU, Chassis Fan multi-speed control
  - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
• - ATX Form Factor: 12.0-in x 8.6-in, 30.5 cm x 21.8 cm
  - Premium Gold Capacitor design (100% Japan made high quality conductive polymer capacitors)
• - Microsoft^® Windows^® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit / Vista™ 32-bit / Vista™ 64-bit / XP 32-bit / XP 64-bit


  *Windows^® 8.1 is supported with Intel^® Ivy Bridge CPU for onboard VGA.
• - FCC, CE
  - ErP/EuP Ready (ErP/EuP ready power supply is required)
